Double Wall Paper Cup Sleeve Machine
Doule wall paper cup machine is a high-speed and high-efficiency paper cup forming auxiliary machine, specially used for forming the outer sleeves and sticking it with the inner paper cup or plastic cups. It need to work together with inner paper cup forming machine. Through machine customization, it can be used to produce hollow insulated cups, double-layer corrugated cups, appressed veneer cups, and appressed embossed veneer cups.
INQUIRY
Product Description
Technical Parameters
Machine Details


Double Wall Paper Cup Sleeve Machine




Instruction:

Doule wall paper cup machine is a high-speed and high-efficiency paper cup forming auxiliary machine, specially used for forming the outer sleeves and sticking it with the inner paper cup or plastic cups. Through machine customization, it can be used to produce hollow insulated cups, double-layer corrugated cups, appressed veneer cups, and appressed embossed veneer cups. You can also choose whether you need to add a hot melt glue box to meet the forming work of the outer sleeve according to the nature of the paper sheet.


Sample:


图片22.1.jpg   图片23.1.jpg   图片24.1.jpg




Model

Middle Speed Paper Cup Machine FT-CUT2100

Paper Cup Specification4-22oz(mold exchangeable) Top diameter: 55-105mm    Height: 60-120mm
Paper Specification170-380GSM Single or Double PE Coated Paper/Krafet Paper
Production Capacity90-100pcs/min
Power Source380V 50HZ 3Phases
Average Power6KW
Air Supply RequirementCompressed air: 0.5-0.8MpaAir outlet: 0.4-0.5cbm/min
Total Weight2400KG
Package Size

Wooden case(L*W*H): 2600*1360*1900mm

Machine more details:




图片2.jpg   图片3.jpg






图片6.jpg   图片7.jpg


图片8.jpg 图片9.jpg
